Key Features
Electric Powered Lifting System
The chair uses a DC24V electric actuator system, allowing smooth and controlled lifting with minimal caregiver effort.
Height Adjustable Design
Seat height can be adjusted from 60–73.5 cm, accommodating different bed, wheelchair, and toilet heights.
Chest + Foot Support System
Equipped with soft chest support and footrest system for stable patient positioning during transfer.
Compact Mobility Design
The 3-inch medical-grade swivel wheels with brakes allow smooth movement even in narrow hospital corridors.
Reinforced Steel Frame Structure
Built with 2.0 mm thick steel tubing, providing strong structural support with a 125 kg load capacity.
PU Waterproof Arm Support
Arm and contact surfaces use PU self-skin foam material, offering comfort and water resistance.
Adjustable Back Support System
Back and chest support height can be adjusted for different patient body types.
Long Battery Runtime
A full charge supports approximately 1 hour of continuous operation, suitable for daily clinical use.
Tool-Free Operation
Simple control system allows caregivers to operate lifting functions easily via control buttons.
Specifications
| Item | Specification |
|---|---|
| Model | KDB505B-B02 |
| Product Type | Electric Patient Transfer Lift Chair |
| Frame Material | Steel, white powder-coated |
| Tube Thickness | 2.0 mm |
| Overall Length | 97 cm |
| Overall Width | 58.5 cm |
| Overall Height | 105–130 cm |
| Seat Depth | 33 cm |
| Seat Width | 50 cm |
| Seat Height Range | 60–73.5 cm |
| Armrest Height | 102–130 cm |
| Armrest to Seat Height | 33–58 cm |
| Back Support Height | 41–52 cm |
| Wheel Type | 3-inch medical casters with brakes |
| Net Weight | 43.32 kg |
| Load Capacity | 125 kg |
| Battery Voltage | DC 24V |
| Battery Capacity | 1800 mAh |
| Charging Input | 100–240V, 1.3A |
| Charging Output | DC 24V 3A |
| Continuous Working Time | ~1 hour |
| Operating Temperature | -20℃ to +60℃ |
| Humidity | ≤80% |
Application Scenarios
Hospitals
Supports safe patient transfer between beds, wheelchairs, and toilets.
Nursing Homes
Reduces caregiver workload during daily mobility assistance.
Rehabilitation Centers
Helps patients during post-surgery recovery and mobility training.
Homecare Services
Provides safe lifting support for elderly or disabled users at home.
Long-Term Care Facilities
Improves efficiency of daily nursing operations and patient handling.
